215kwh Bess Containerized Battery Energy Storage System
------Containerized Battery Storage
Details (Containerized Energy Storage)
1. High Efficiency
Transformer-less design, higher system efficiency.
Wide AC Grid voltage range.
Smart Air cooling, energy saving.
Single battery string. No circular current.
Saving battery capacity loose.
2. Flexible Application
Modular Design, flexible configuration, small footprint.
Power module supports “N+1"redundancy.
All in One design. Easy Installation & maintenance.
3. Safety& Reliability
Full function of heat management, fault detection and protection.
Inbuilt BMS, PCS, MPPT and EMS. Multiple levels of software & Hardware protection.
Two level fire extinguisher system.
4. Full Function
Fast reaction of Active/Reactive power adjustment.
STS Inbuilt Supporting On grid/ off grid transfer without interrupted.
Standard with EMS function. Peak saving, virtual enlargement, EPS,
New Energy power absorption.
Parameters:
| AC data | |||
| Model | ESSO100B215 | ||
| Rated power (kW) | 100 | ||
| Rated voltage (V) | 400 | ||
| Rated current (A) | 144 | ||
| Voltage range (V) | 320V-460V | ||
| Rated frequency | 50/60Hz | ||
| Frequency Range | 45-55/55-65Hz | ||
| THDi(on-grid) | <3% | ||
| THDu (off-grid) | ≤ 1% linear; ≤ 5% non-linear | ||
| Power factor | 1 (0.8 leading ~ 0.8 laging can be set) | ||
| Overload capacity | 110% Long term | ||
| AC output | 3W+N+PE | ||
| Isolation transformer | 270/400 | ||
| On -grid off-grid switching | Support | ||
| PV data | |||
| Max.PV input voltage (V) | 1,000 | ||
| Max. PV power (kW) | 120/180/240 | ||
| MPPT operating voltage range (V) | 250~850 | ||
| MPPT full load voltage range (V) | 450~850 | ||
| Buck-boost mode | Support | ||
| Battery data | |||
| Cell type | 3.2V/280Ah/1C,LFP | ||
| Nominal voltage(V) | 768V，1P240S | ||
| Nominal energy (kWh) | 215.04 | ||
| Working voltage range (V) | 672~850 | ||
| Max. charge and discharge rate | 0.5C@25℃ | ||
| Number of Battery Cycles | ≥3,800 | ||
| System data | |||
| Dimensions W *D *H (mm) | 2,450*1,550*2,400 | ||
| Net weight (kg) | 3900 | ||
| Operating temperature (℃) | 0 ～ +45 | ||
| Relative humidity | 0 ~95%（non-condensing） | ||
| Ingress protection | IP54 | ||
| Noise emission (dB) | <75 | ||
| Operating altitude | 3,000m | ||
| Cooling | Intelligent air cooling | ||
| fire extinguishing system | Aerosols/NOVEC1230 | ||
| Display | Touch LCD display+cloud platform | ||
| EMS communication | RS485，TCP/IP | ||
